51cm Olmo San Remo Vintage Italian Road Bike Frame

✓ Original vintage frame - built in the 1980s
✓ Lightweight for the era - just 2.6 kg
✓ Suitable for historic cycling events such as L'Eroica
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping

Established in Italy in 1939, Olmo are still producing bicycles today, however their heyday of technologically advanced, lightweight race winning bikes was through the 70s and 80s. Guiseppe 'Gepin' Olmo was a very quick rider in his day, at one point holding the hour record, and as was the standard career trajectory of the time once he retired he started a bike brand bearing his name. The Olmo company grew quickly and diversified into other industries through the years, and whilst they produced a large number of bikes they were responsible for building some incredibly high end ones too.

The Olmo San Remo appeared in the mid 80s as a more value for money version of their absolute top end race bikes. Made in the Olmo factory alongside the bikes they were building for professionals at the time, the San Remo featured a double butted Columbus tube set, chromed forks and rear end, and was available in a choice of paint schemes. This frame is probably from the late 1980s and features a wonderful Mondrian influenced primary colour on grey paint scheme.

If you're taking part in L'Eroica or a similar vintage event, this frame is of the correct age, so you won't be disqualified for being a rule breaker!

The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.

OVERVIEW


Era - 1980s
Country - Italian
Frame Material - Steel
Tubing - Columbus Cromor
Weight - 2.645 kg
Stock Code - U-F-R44V

SIZING


Size Guide* - Small (Approx 30" Inside Leg)
Seat Tube (ctc) - 51 cm
Top Tube (ctc) - 53 cm
Head Tube - 100 mm
Chainstay Length - 40.5 cm
Wheelbase - 98 cm

*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.

TECHNICAL INFO


Rear Spacing - 126 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Brake Drop - 47 mm / 48 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 38 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
