54.5cm Hirame c.1982 Vintage Road Bike Frame
✓ Original vintage frame - built in the 1980s
✓ Suitable for historic cycling events such as L'Eroica
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
Built in Japan by Kuwahara, and imported to the UK by Evian in London, Hirame were available throughout the 70s and early 80s and offered a range of high quality frames at a great value for money price. Japan was the best mass producer of bikes through the 1970s and Kuwahara produced a huge number of well built bikes for various brands and markets. Hirame frames are generally built with Ishiwata tubing and neat cast lugs, the number of braze-ons usually indicates how high up the range the bike sits.
The Kando was Hirame's entry level model, and though put together with Hi-Tension steel and without a full array of braze-ons it was still hand-built in Japan by Kuwahara to a very high standard. The Kando was designed for ample clearance front and rear allowing the customer to use a 700c tubular racing wheel if desired, but more practically suited to a wider 27" wheel with mudguards. Like most Hirame models the Kando was only available in one colour, in this case a deep metallic red.
If you're taking part in L'Eroica or any other vintage event, this frame is of the correct age, so you won't be disqualified for being a rule breaker!
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.
JapaneseFrame Material -
Hi-Tension SteelWeight -
3.57 kgStock Code -
Size Guide* - Medium (Approx 32" Inside Leg)
Seat Tube (ctc) - 54.5 cm
Top Tube (ctc) - 55 cm
Head Tube - 135 mm
Chainstay Length - 44.5 cm
Wheelbase - 103.5 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
Rear Spacing -
126 mmFront Spacing -
100 mmSeatpost Diameter -
25.8 mmWheel Size -
27"Brake Fixing -
External Hex NutBrake Drop -
59 mmBottom Bracket Thread -
English/British/ISO ThreadHeadset Thread -
Standard ISO (24 TPI - British/Italian)Headset Stack Height -
35 mmFork Crown Race -
27.0 mm (JIS)Shifter Fittings -
Downtube Band-OnHeadtube Internal Diameter -
30.0 mmSteerer Internal Diameter -
22.2 mm (Standard)
