48.5cm Lexpres Vintage Belgian Track Bike Frame
£450.00
✓ Original vintage frame - built in the 1970s
✓ Lightweight for the era - just 2.6 kg
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
Lexpres was a small cycle shop in Antwerp, Belgium that built (or had built for them) bikes bearing their name in the late 1970s and early 1980s. There are very few examples of their bikes still in circulation, but it seems that track bikes were a speciality.
It is built from lightweight but strong Ishiwata 022 tubing with Shimano horizontal dropouts and Bocama lugs, and is not drilled for a brake. The frame is stamped '77' on the bottom bracket shell which given the frame details suggest this could well be the year of manufacture. With it's original paintwork and transfers this classic frameset is ready to be built up and put back to work on the boards.
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1970s
Country - Belgian
Frame Material - Steel
Tubing - Ishiwata 022
Weight - 2.555 kg
Stock Code - U-F-T5V
SIZING
Size Guide* - XS/Small (Approx 28 1/2" Inside Leg)
Seat Tube (ctc) - 48.5 cm
Top Tube (ctc) - 52 cm
Head Tube - 89 mm
Chainstay Length - 41 cm
Wheelbase - 95 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 120 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.0 mm
Wheel Size - 700c/28"
Bottom Bracket Thread - English/British/ISO Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 34 mm
Fork Crown Race - 26.4 mm (ISO)
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
48cm Mino Denti Mistral Vintage Italian Road Bike Frame
£895.00
✓ Original vintage frame - built in the 1980s
✓ Super lightweight for the era - only 2.3 kg!
✓ Suitable for historic cycling events such as L'Eroica
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
Mino Denti was a great Italian racer who rode for some fantastic teams throughout the 1960s, he would probably be classed as a super-domestique these days as he was often found riding for the bigger names on his team. After his racing career ended in the late 1960s, Mino worked in the management side of professional cycling before taking the well-trodden path to starting his own bicycle business in 1979. Unlike most of his contemporaries, Mino decided he would do the building himself, and whilst there are very few Mino built frames out there, they're all beautifully finished and often sports unusual features such as hand-crimped tubes or bent seat tubes.
At just 48cm, this Mino Denti Mistral is just about as small a vintage road bike frame as you are likely to find. Built from super lightweight Columbus butted tubing and with aerodynamics in mind, it probably dates from the late 1980s. The shifter mounts are located on top of the downtube and the cables are routed into the downtube, then out again by the bottom bracket where they loop round on the outside of the frame to the derailleurs. The most interesting and unique feature here though has to be the Columbus Air flattened fork and chainstays for super aero appeal, and of course the short head tube promotes a streamlined head down/bum up position on the bike.
If you're taking part in L'Eroica or a similar vintage event, this frame is of the correct age, so you won't be disqualified for being a rule breaker!
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1980s
Country - Italian
Frame Material - Steel
Tubing - Columbus (Air fork & chainstays)
Weight - 2.345 kg
Stock Code - U-F-R55V
SIZING
Size Guide* - XS/Small (Approx 28 1/2" Inside Leg)
Seat Tube (ctc) - 48 cm
Top Tube (ctc) - 53 cm
Head Tube - 78 mm
Chainstay Length - 40 cm
Wheelbase - 97 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 126 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Brake Drop - 42 mm / 48 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 42 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Aero Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
49cm Chas Roberts c.1991 Classic British Steel Road Bike Frame Set
£595.00
✓ Original classic frame - built in the 1990s
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
South London's finest, Roberts Cycles are known the world over but have a particular cache as a classy frame-builder in the UK. Charlie Roberts honed his craft building frames post-war for various London brands, including Claud Butler and Holdsworth, but decided to strike out on his own in the 1960s. Later, his sons Chas and Geoff were passed the torch. With Charlie's passing in the late '70s, Chas took over the management of the company, and Geoff built alongside Derek Bailey, producing more and more custom road, track, pursuit, and touring frames to an increasing number of admirers. In the early '80s, Winston Vaz joined and spearheaded the production of their mountain bike frames, notably the White Spider and D.O.G.S B.O.L.L.O.X. The brand is now highly sought after by collectors.
This lightweight 1991-built frame is a lovely example of the restrained but well-made custom frames coming out of Roberts' workshop at the time. Made from Reynolds 531 Professional, Reynolds' lightest version of the 531 tube set, it was recommended for racing only due to its thin walls. As was the fashion at the time, the frame has an internally routed rear brake cable, close clearances, and a Cinelli 'spoiler' BB. We suspect the frame has had a fairly recent repaint, as it is in lovely condition with a nice contrasting black and red colour scheme.
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1990s
Country - British
Frame Material - Steel
Tubing - Reynolds 531 Professional
Weight - 2.625 kg
Stock Code - U-F-R114C
SIZING
Size Guide* - XS/Small (Approx 29" Inside Leg)
Seat Tube (ctc) - 49 cm
Top Tube (ctc) - 51.5 cm
Head Tube - 91 mm
Chainstay Length - 40.5 cm
Wheelbase - 97 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 128 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Front Brake Drop - 42 mm
Rear Brake Drop - 41 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 37 mm
Fork Crown Race - 26.4
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
-
▼HELP SECTION
-
Seat Tube (ctc) - we measure from the centre of the bottom bracket shell up to the centre line of the top tube to give a consistent measurement regardless of frame design (ctc means centre to centre).
Top Tube (ctc) - this is measured from the centre of the head tube to the centre of the seat tube, along the centre of the top tube.
Chainstay Length - measured from the centre of the bottom bracket shell to the centre point of the rear dropout.
Wheelbase - measured from the centre of the front fork dropout to the centre point of the rear dropout.
Front & Rear Spacing - measured from the inside of one dropout to the other. The dropouts on steel frames can be stretched or squeezed a few mm but it's always best to avoid this if possible, aluminium or carbon frames should never be stretched.
Brake Drop - measured using wheels of the relevant size for the frame, as stated in the technical info section.
Headset Threads - although it's generally recommended to match threaded parts exactly, with headsets you can technically mix and match, unless you have French or the obscure old Raleigh threads, in which case you need to stick to that type.
52.5cm Kestrel 4000 Vintage American Road Bike Frame
£895.00
✓ Original vintage frame - built in the 1980s/90s
✓ Super lightweight for the era - only 2.3 kg!
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
The brainchild of composite visionary Brent Trimble, along with former employee's of Trek and Blackburn, Kestrel was launched onto the scene in the late 1980s by Cycle Composites Inc. Beginning with a game-changing monocoque road bike that graced the front cover of magazines and was immediately raced to devestating effect in 1987, followed by the first full suspension carbon MTB (with V Brakes!) in 1988. Through the early adoption of computer aided design and aerodynamics, Kestrel can be credited with creating the genesis of the high-performance carbon road bike that is so prevalent today.
Taking eight years to design, test and prepare for manufacture the 4000 emerged as a fully formed, ready to race super bike in 1987. The first mass-produced carbon monocoque road bike available, it looked like nothing else, and importantly rode like nothing else too. The new technology that went into the building the 4000 resulted in a stiff, comfortable, light, well balanced frame, something of a first for carbon. To top it off it also had a strong aerodynamic benefit with its profiled shape and internal cable routing. As well as the cutting edge technology of the time, renowned bike designer and engineer Keith Bontrager advised on the geometry which pulled together into a phenomenal race bike.
This example of the legendary Kestrel 4000 frame was built in 1990, towards the end of the production run and is spaced for 6 or 7 speed drivetrains at the rear. With the classic Imron white paintwork in great order and very few marks, this rare machine was obviously well looked after and is ready to give many more years of service.
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1980s/1990s
Country - American
Frame Material - Carbon Fibre / Aluminium
Weight - 2.345 kg
Stock Code - U-F-R85V
SIZING
Size Guide* - Small/Medium (Approx 31" Inside Leg)
Seat Tube (ctc) - 52.5 cm
Top Tube (ctc) - 54.5 cm
Head Tube - 120 mm
Chainstay Length - 41 cm
Wheelbase - 98 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 128 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Front Brake Drop - 45 mm
Rear Brake Drop - 44 mm
Bottom Bracket Thread - English/British/ISO Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 40 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
-
▼HELP SECTION
-
Seat Tube (ctc) - we measure from the centre of the bottom bracket shell up to the centre line of the top tube to give a consistent measurement regardless of frame design (ctc means centre to centre).
Top Tube (ctc) - this is measured from the centre of the head tube to the centre of the seat tube, along the centre of the top tube.
Chainstay Length - measured from the centre of the bottom bracket shell to the centre point of the rear dropout.
Wheelbase - measured from the centre of the front fork dropout to the centre point of the rear dropout.
Front & Rear Spacing - measured from the inside of one dropout to the other. The dropouts on steel frames can be stretched or squeezed a few mm but it's always best to avoid this if possible, aluminium or carbon frames should never be stretched.
Brake Drop - measured using wheels of the relevant size for the frame, as stated in the technical info section.
Headset Threads - although it's generally recommended to match threaded parts exactly, with headsets you can technically mix and match, unless you have French or the obscure old Raleigh threads, in which case you need to stick to that type.
52.5cm Pinarello Veneto Classic Italian Steel Road Bike Frame Set
£525.00
✓ Original classic frame - built in the 1990s
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
The Pinarello story is a magnificent one, from Giovanni Pinarello taking the Maglia Nera (Black Jersey for last place) in the 1951 Giro D’Italia to the dominance of Pinarello in the cycling world today. It truly is a fairy tale, from being left out of the 1952 Giro and taking the opportunity to open his own tiny workshop in Treviso, Italy, and from there Giovanni built the Cicli Pinarello brand from the ground up. Bit by bit the success came, and with a reputation for taking the underdogs and turning them into champions, slowly but surely Pinarello went from minnows to the giants they are today.
A mainstay in the Pinarello range for many years, the Veneto utilised their expertise in building top end race frames to construct a lower cost but still high quality frame. Often found built with a slightly heavier guage of tubing such as Columbus Aelle the Veneto was offered as a frame only option with Pinarello's usual wide choice of paint colours and finishes, and also sold as a bike with a full mid-range groupset from Shimano or Campagnolo.
This beautiful example of a Veneto is finished in classic 'Rosso Pinarello' and is built from Columbus Aelle tubing. From the end of the era of down-tube shifters, 1” forks, and steel being the material of choice, this early '90s frame represents 40 years of frame-building experience at Pinarello. In really nice condition, with a fully chromed replacement fork.
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1990s
Country - Italian
Frame Material - Steel
Tubing - Columbus Aelle
Weight - 0 kg
Stock Code - U-F-R121C
NB - Replacement fork
SIZING
Size Guide* - Small/Medium (Approx 31" Inside Leg)
Seat Tube (ctc) - 52.5 cm
Top Tube (ctc) - 53.5 cm
Head Tube - 108 mm
Chainstay Length - 40.5 cm
Wheelbase - 98.5 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 129 mm
Front Spacing - 99 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Front Brake Drop - 49 mm
Rear Brake Drop - 45 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 39 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
-
▼HELP SECTION
-
Seat Tube (ctc) - we measure from the centre of the bottom bracket shell up to the centre line of the top tube to give a consistent measurement regardless of frame design (ctc means centre to centre).
Top Tube (ctc) - this is measured from the centre of the head tube to the centre of the seat tube, along the centre of the top tube.
Chainstay Length - measured from the centre of the bottom bracket shell to the centre point of the rear dropout.
Wheelbase - measured from the centre of the front fork dropout to the centre point of the rear dropout.
Front & Rear Spacing - measured from the inside of one dropout to the other. The dropouts on steel frames can be stretched or squeezed a few mm but it's always best to avoid this if possible, aluminium or carbon frames should never be stretched.
Brake Drop - measured using wheels of the relevant size for the frame, as stated in the technical info section.
Headset Threads - although it's generally recommended to match threaded parts exactly, with headsets you can technically mix and match, unless you have French or the obscure old Raleigh threads, in which case you need to stick to that type.
52cm Bottecchia Battaglin Branded Vintage Italian Road Bike Frame
£425.00
✓ Original vintage frame - built in the 1980s
✓ Super lightweight for the era - only 2.5 kg!
✓ Suitable for historic cycling events such as L'Eroica
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
Though branded with Battaglin decals from the late 1980s, this appears to be a curious mix of a Bottecchia built frame with a Berma pantographed fork. The frame lugs carry the distinctive Bottecchia cut out shape, and the internal cable routing is in a style they used too, whilst the fork carries the Berma 'B' on the fork crown. The purple and neon yellow colour scheme is reminiscent of the Team Jolly Componibili colours, who rode on Battaglins in the 80s and 90s. With Campagnolo dropouts front and rear and a slotted bottom bracket this is a well made frame, regardless of its slightly confused identity!
If you're taking part in L'Eroica or a similar vintage event, this frame is of the correct age, so you won't be disqualified for being a rule breaker!
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1980s
Country - Italian
Frame Material - Steel
Tubing - Columbus Aelle
Weight - 2.46 kg
Stock Code - U-F-R64V
SIZING
Size Guide* - Small/Medium (Approx 30 1/2" Inside Leg)
Seat Tube (ctc) - 52 cm
Top Tube (ctc) - 53 cm
Head Tube - 114 mm
Chainstay Length - 40.5 cm
Wheelbase - 97.5 mm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 126 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.2 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Brake Drop - 43 mm / 40 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 33.0 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
53.5cm Ciocc Designer 84 Vintage Italian Steel Road Bike Frame Set
£450.00
✓ Original vintage frame - built in the 1980s
✓ Lightweight for the era - just 2.8 kg
✓ Suitable for historic cycling events such as L'Eroica
✓ Thoroughly checked over & photographed in detail
✓ Worldwide shipping
Ciöcc bagan in the 1970s when ex-racer Giovanni Pelizzoli turned his hand to building high quality frames in Northern Italy. Pelizzoli is considered one of the greatest frame-builders of his generation and many Ciöcc were raced through the 70s and 80s. The top of the range bikes were named after successes in San Cristobel in 1977 and the 1980 Moscow Olympics (the Mockba '80) though there were no doubt many other victories on rebranded Ciöcc frames too as was the norm at the time. Pelizzoli parted company with the brand some time in the 1980s but the company continued building with the knowledge he had imparted to them and they still make bikes (albeit far different ones!) today.
Although this delightfully finished frame has none of the trademark Ciocc pantographs or engravings, the details match those of the Designer 84 model it's badged as. With a very neat black to dark purple metallic fade paint job with chromed rear triangle and fork, this is a very well put together frame. The lugs and small frame details are all in line with other Ciocc frames of the period too. Internal rear brake routing and a braze-on for the front mech date it to the mid 1980s, and it has obviously led an easy life up to now.
If you're taking part in L'Eroica or a similar vintage event, this frame is of the correct age, so you won't be disqualified for being a rule breaker!
The frame's been carefully checked by one of our mechanics to confirm the alignment's correct and there's no damage to the threads. If there are any minor issues worth noting we will do so in the overview section below. Please take a good look at the detailed photos so you can see the cosmetic condition of the frame before you buy.OVERVIEW
Era - 1980s
Country - Italian
Frame Material - Steel
Weight - 2.805 kg
Stock Code - U-F-R87V
SIZING
Size Guide* - Small/Medium (Approx 31 1/2" Inside Leg)
Seat Tube (ctc) - 53.5 cm
Top Tube (ctc) - 54 cm
Head Tube - 120 mm
Chainstay Length - 41 cm
Wheelbase - 98 cm
*This is just a guide, not a guarantee the frame will fit as every rider is different. If you're unsure of your size we'd always recommend trying out a bike with similar frame dimensions first.
TECHNICAL INFO
Rear Spacing - 126 mm
Front Spacing - 100 mm
Seatpost Diameter - 27.0 mm
Wheel Size - 700c/28"
Brake Fixing - Recessed Allen Key
Front Brake Drop - 52 mm
Rear Brake Drop - 44 mm
Bottom Bracket Thread - Italian Thread
Headset Thread - Standard ISO (24 TPI - British/Italian)
Headset Stack Height - 46 mm
Fork Crown Race - 26.4 mm (ISO)
Shifter Fittings - Downtube Braze-On
Headtube Internal Diameter - 30.2 mm
Steerer Internal Diameter - 22.2 mm (Standard)
-
▼SHIPPING, TAXES & RETURNS
-
We've been safely sending orders around the world since 2010. There's a handy shipping calculator on the shopping cart page so you can see the cost of postage as soon as you've added it to your basket. Your order will be carefully packed and sent with tracking & insurance, we despatch most orders within 2-3 days but larger items and orders placed before the weekend can take an extra day or two to process.
We accept returns, please notify us within 14 days and ensure the item arrives back with us no later than 30 days after the order was received.
We don't charge VAT, however, if buying from outside of the UK please remember that there may be import fees to pay directly to the delivery company before receiving the order. Unfortunately we can’t advise on the exact costs as it varies from country to country, so please check your national rates before purchasing.
-
▼HELP SECTION
-
Seat Tube (ctc) - we measure from the centre of the bottom bracket shell up to the centre line of the top tube to give a consistent measurement regardless of frame design (ctc means centre to centre).
Top Tube (ctc) - this is measured from the centre of the head tube to the centre of the seat tube, along the centre of the top tube.
Chainstay Length - measured from the centre of the bottom bracket shell to the centre point of the rear dropout.
Wheelbase - measured from the centre of the front fork dropout to the centre point of the rear dropout.
Front & Rear Spacing - measured from the inside of one dropout to the other. The dropouts on steel frames can be stretched or squeezed a few mm but it's always best to avoid this if possible, aluminium or carbon frames should never be stretched.
Brake Drop - measured using wheels of the relevant size for the frame, as stated in the technical info section.
Headset Threads - although it's generally recommended to match threaded parts exactly, with headsets you can technically mix and match, unless you have French or the obscure old Raleigh threads, in which case you need to stick to that type.
